Stereo Integrated Amplifier AM-2350

• Country
• Japan

• Manufacturer / Brand
• Akai Electric Co., Ltd.; Tokyo

• Year
• 1978 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 253208

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 70 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Integrated Amplifier AM-2350 - Akai Electric Co., Ltd.; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 380 x 123 x 241 mm / 15 x 4.8 x 9.5 inch

• Notes

• Power output: 35 watts per channel into 8Ω (stereo).
  Speaker load impedance: 4Ω to 16Ω.

• Net weight (2.2 lb = 1 kg)
• 7.1 kg / 15 lb 10.2 oz (15.639 lb)

• Author
• Model page created by Bartosz Szwed. See "Data change" for further contributors.
