Precision audio component / tuner amp DRA-550
Denon (Marke / brand)
- Country
- Japan
- Manufacturer / Brand
- Denon (Marke / brand)
- Year
- 1986
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 143974
Original prospekt in 1986.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 100 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Precision audio component / tuner amp DRA-550 - Denon Marke / brand
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 434 x 112 x 400 mm / 17.1 x 4.4 x 15.7 inch
- Notes
- AM/FM-Receiver mit 2 x 50 Watt Sinus an 8 Ohm. 16 frei programmierbare Stationstasten, einstellbare Loudness-Regelung.
Gehäuseausführung Silber oder Schwarz.
- Net weight (2.2 lb = 1 kg)
- 7.9 kg / 17 lb 6.4 oz (17.401 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
