Electronic TR-1400

• Country
• Germany

• Manufacturer / Brand
• Elite; Kaufhof

• Year
• 1981 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 246546

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 5

• Semiconductors
• 2SC763 2SC763 2SK41 2SA628 2SC711 TA7614 LA3361 LA4140 LA4140

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, more than 2 SW bands plus FM or UHF.

• Power type and voltage
• Batteries / addl. power jack / AA: 4 × 1,5 / 6 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 cm = 3 inch

• Power out
• 0.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Electronic TR-1400 - Elite; Kaufhof

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 180 x 116 x 35 mm / 7.1 x 4.6 x 1.4 inch

• Notes

• MW/UKW/KW 1.2.3.4 - 6-Band Radio mit UKW-Stereo Empfänger, Frequenzbereiche: UKW-87,5 - 108 MHz, MW-525 - 1605 KHz, KW1- 2,3 - 4 MHz, KW2- 4 - 7,5 MHz, KW3-7,5 - 15 MHz, KW4- 15 - 26,2 MHz, Stereo,- Feldstärke und Batterie-Zustandsanzeige über LED, getrennte Lautstärkeregler, Klangschalter, Anschlußmöglichkeit für ext. Netzgerät (DC 6 Volt) und 2 Kopfhörer über Klinkenbuchsen 3,5 mm.
  Siehe auch Tristar TR 1400.

• Net weight (2.2 lb = 1 kg)
• 0.450 kg / 0 lb 15.9 oz (0.991 lb)

• Price in first year of sale
• 98.00 DM

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 37 models, 36 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Elite; Kaufhof
