• Country
• United States of America (USA)

• Manufacturer / Brand
• Day-Fan Electric Co.; Dayton, Ohio (Fan and Motor Company)

• Year
• 1926

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 42803

• • alternative name: Dayton Fan and Motor Co.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown); 2 AF stage(s)

• Tuned circuits
• 3 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries / ? & 22.5 & 67.5 & 90 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Day-Fan 6 5121 - Day-Fan Electric Co.; Dayton,

• Shape
• Console, Highboy (legs > 50 %).

• Notes
• Console table (Wandtisch). One dial (primary tuning control knob) ; Both Grinders Collectors Guide and Riders are in error when they allocate pre 1930 models to GM Radio.

• Price in first year of sale
• 100.00 $

• External source of data
• Ernst Erb

• Source of data
• Radio Collector`s Guide 1921-1932

• Other Models

• Here you find 109 models, 38 with images and 44 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
