HiFi Receiver R 30
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1984
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 131831
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Original prospekt, in 1985.
Original prospekt, in 1985.
Aus Grundig TI 1/2-1984
Q: Grundig, HiFi-Programm '84
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 60 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: HiFi Receiver R 30 - Grundig Radio-Vertrieb, RVF,
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 320 x 70 x 270 mm / 12.6 x 2.8 x 10.6 inch
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
