• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1976/1977

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 110226

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 41

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     14 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-130; 220-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Various materials

• from Radiomuseum.org
• Model: HIFI-Studio RP300 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Notes
• ICs: 8.
  Ausgangsleistung: 2× 50 W (Musik) bei Stereo bzw. 4× 30 W (Musik) bei 2-Raum-Stereo; 7 UKW-Sender fix abstimmbar und über Sensortasten abrufbar;
  Phono-Chassis = Dual 1226 mit Magnetsystem Shure M75-D;
  Cassetten-Deck CN500 kann nachträglich eingebaut werden.
  2 Ausführungen:
  RP300 = Gehäuse metallic
  RP300a = Gehäuse schwarz.

• Source of data
• Handbuch VDRG 1976/1977

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Wolfgang Bauer. See "Data change" for further contributors.
