• Country
• Austria

• Manufacturer / Brand
• Horny (Hornyphon); Wien

• Year
• 1959

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 84416

• • Brand: Hornyphon

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• PCC88 PCF80 EF80 EF80 EF80 EF80 EF80 PCL82 PCL84 ECC81 PCF80 PCF80 ECH81 PCL82 PL81 PY81 DY87 PY82 PY82 AW53-80

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Weltmeister 53 WK2118U /10 Ch= S4 - Horny Hornyphon; Wien

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Ausführung mit 5 Tasten und Abstimmanzeige "Bildmagnet".
  Bei gedrückter Taste "Abstimmanzeige" dunkler, senkrechter Balken im Bild. Breite abhängig von der optimalen Senderabstimmung.

  Empfangsbereich: Band I + III, Kanal 2a - 4, 5 - 12.

  Parallelgerät zum Philips 21CA181U/10.

• Price in first year of sale
• 9,100.00 ATS

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
