• Country
• Japan

• Manufacturer / Brand
• Leader Electronics Corp.; Yokohama

• Year
• 1984 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 269598

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Laser Power Meter LPM-8000-01 - Leader Electronics Corp.;

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 90 x 31 x 140 mm / 3.5 x 1.2 x 5.5 inch

• Notes

• Der Sensor hat Bezeichnung LPM 8000-01, das Instrument LPM-8000.

• Net weight (2.2 lb = 1 kg)
• 0.250 kg / 0 lb 8.8 oz (0.551 lb)

• Mentioned in
• Funkschau (20/1984, S. 77 / Bericht)

• Author
• Model page created by Jürgen Küting. See "Data change" for further contributors.
