Universum System HiFi 7500 SL V2315A

QUELLE GmbH (Universum); Fürth und Nürnberg

  • Year
  • 1981 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 154200

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 22
  • Semiconductors
  • Main principle
  • Audio-Amplification; 2 AF stage(s)
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 60 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Universum System HiFi 7500 SL V2315A - QUELLE GmbH Universum; Fürth
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 440 x 80 x 320 mm / 17.3 x 3.1 x 12.6 inch
  • Notes
  • Silizium- und Germanium-Transistoren, 6 ICs, 13 Dioden. Tuner T2314, Tapedeck und den Plattenspieler F2010.
  • Net weight (2.2 lb = 1 kg)
  • 7.5 kg / 16 lb 8.3 oz (16.52 lb)
  • Price in first year of sale
  • 899.00 DM
  • Mentioned in
  • - - Manufacturers Literature
