• Country
• Great Britain (UK)

• Manufacturer / Brand
• Racal Engineering / Instruments / Electronics Ltd., Bracknell

• Year
• 1980 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 240821

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Line / Storage batteries (perhaps also batteries) / 212-238; 224-251 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: UHF Frequency Counter 9916 - Racal Engineering /

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 241 x 84 x 268 mm / 9.5 x 3.3 x 10.6 inch

• Notes

• Racal-Dana Frequenzzähler Modell 9916

  - Zählbereich: 0,1 Hz bis 520 MHz
  - Messzeit: 0,01 sec. bis 10 sec.
  - Anzeige: 8-Digit 7-Segment LED
  - Empfindlichkeit: 10 mV, automatische Pegelanpassung (AGC)
  - Option: 04A (3x 10E-9/Tag Ofenoszillator) eingebaut



• Net weight (2.2 lb = 1 kg)
• 2.7 kg / 5 lb 15.2 oz (5.947 lb)

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Walter Fackler. See "Data change" for further contributors.
