Stereo Cassette Deck RT-442X
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1972–1975
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 220573
-
- alternative name: Hayakawa Electric Co.Ltd.
Mingay's Price Service, 2/75.
Bild aus Sharp Service Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 14
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 220; 240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Stereo Cassette Deck RT-442X - Sharp; Osaka
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 387 x 121 x 287 mm / 15.2 x 4.8 x 11.3 inch
- Notes
-
Sharp Model RT-442X
Solid state 4-track stereo cassette deck. Pin-point volume slide controls provide perfect balance for maximum stereo separation. Dual illuminated VU meters indicate audio input and output. Automatic shut off if tape runs out. Convenient 3-digit tape counter. Multiple AC voltage operation. (MINGAY'S PRICE SERVICE)
Frequency response: 30 -15,000Hz for low noise high-output tape, 30 - 12,000Hz for standard tape. S/N ratio: 50dB.
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Price in first year of sale
- 143.00 AUS $
- Mentioned in
- Mingay's Price Service (Aug 1972 to Aug 1975.)
- Literature/Schematics (1)
- -- Original-techn. papers. (Sharp Service Manual.)
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
