• Country
• Austria

• Manufacturer / Brand
• Siemens-Austria (WSW); Wien

• Year
• 1954 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 163716

• • alternative name: Ges. für Technische Glaswaren
  • Brand: Wiener Schwachstrom Werke (WSW)

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 185; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 25 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Elaphon-Verstärker SG910/1 [Mit Radio] - Siemens-Austria WSW; Wien

• Notes
• Das Verstärkerteil von Siemens Halske "Elaphon SG910/1" verfügt über eine Triodenvorstufe, Phasenumkehrstufe und Gegentakt Endstufe. Frequenzbereich 30 - 15000 Hz.

  ---

  Zwischen dem Elaphon 910/1 und Elaphon 910/2 ist laut Prospekt kein Unterschied erkennbar.

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
