Mike-Phone

Team Electronic GmbH; Frankfurt/Main

Data
Forum
Pictures
Collections

  • Year
  • 1990 ??
  • Category
  • Citizen Band Equipment
  • Radiomuseum.org ID
  • 196665

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 10695/455 kHz
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 13,2 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 0.8 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Mike-Phone - Team Electronic GmbH;
  • Shape
  • Miscellaneous shapes - described under notes.
  • Dimensions (WHD)
  • 77 x 41 x 200 mm / 3 x 1.6 x 7.9 inch
  • Notes
  • CB-Mobilfunkgerät bestehend aus Mikrofon mit allen Bedien- und Anzeigeneinrichtungen und separatem Sende-Empfangsteil. Verbunden werden beide Teile über ein langes vieladriges Verbindungskabel, deshalb kann das Sende-Empfangsteil verdeckt im Kofferraum eines PKW montiert werde. 40K FM 4W,12K AM 1W.
  • Net weight (2.2 lb = 1 kg)
  • 0.750 kg / 1 lb 10.4 oz (1.652 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
