Lotos 4211U-6
Tesla; Praha, Bratislava etc.
- Country
- Czechoslovakia
- Manufacturer / Brand
- Tesla; Praha, Bratislava etc.
- Year
- 1961–1964
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 87939
-
- Brand: Supraphon
Detailbild aus ID = 189964 von Herrn Spitzer
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- PCC88 PCF82 EF80 EF80 EF80 EF80 EF80 PCL84 PABC80 PL84 ECH81 EAA91 PCL82 PCF82 PL36 PY88 DY86 531QQ44 or AW53-88
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 2.5 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Lotos 4211U-6 - Tesla; Praha, Bratislava etc.
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 540 x 440 x 380 mm / 21.3 x 17.3 x 15 inch
- Notes
-
Bildröhre-Diagonale 53 cm; LS 1× oval 200 × 150 mm, 1 × oval 50 x 75 mm; empfängt auf 10 Fernsehkanälen CCIR-Norm Band I und III.
Gerät wurde in dieser Ausführung speziell in die DDR eingeführt. Die tschechische Version war nur mit OIRT-Norm erhältlich.
- Net weight (2.2 lb = 1 kg)
- 28 kg / 61 lb 10.8 oz (61.674 lb)
- Price in first year of sale
- 1,750.00 DM
- Author
- Model page created by Wolfgang Lill. See "Data change" for further contributors.
