Magnetic-Tape-Recorder T1500

• Country
• United States of America (USA)

• Manufacturer / Brand
• Wollensak 3M; St. Paul, Minnesota

• Year
• 1957 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 109461

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 12AB5 12AB5 12AX7 12AT7 Neon_Indicator

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Power out
• 2.5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Magnetic-Tape-Recorder T1500 - Wollensak 3M; St. Paul,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 10.3 x 6.5 x 11.8 inch / 262 x 165 x 300 mm

• Notes

• Two speed monaural reel-to-reel tape recorder, with neon indicator for recording level control.
  Mono-Tonbandgerät mit 2 Geschwindigkeiten. Spulendurchmesser max. 18 cm. 3-stelliges Zählwerk. Eingänge: Phono, Radio, Mikrofon. Anschluß für ext. Lautsprecher. Mitgeliefertes Mikrofon: B-162-4. Leistungsaufnahme ca 100 Watt/60 Hz

• Net weight (2.2 lb = 1 kg)
• 8.2 kg / 18 lb 1 oz (18.062 lb)

• Price in first year of sale
• 190.00 $

• Source of data
• -- Collector info (Sammler)

• Mentioned in
• Photofact TR Tape Recorder Manual SAMS (Date 5-58, Set 400, Folder 13)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
