Frankfurt TR de Luxe 24V ab E 796001

Blaupunkt (Ideal), Berlin, später Hildesheim

Data
Forum
Pictures
Collections

  • Year
  • 1961/1962
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 24079
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Number of Transistors
  • 3
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 7 AM circuit(s)     11 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 24 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 6 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Frankfurt TR de Luxe 24V ab E 796001 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 183 x 82 x 168 mm / 7.2 x 3.2 x 6.6 inch
  • Notes
  • UKW: 87 - 100 MHz
    MW: 519 - 1640 kHz
    LW: 150 - 400 kHz

    Transistorteil 183 × 86 × 47mm
  • Net weight (2.2 lb = 1 kg)
  • 3.4 kg / 7 lb 7.8 oz (7.489 lb)
  • Price in first year of sale
  • 365.00 DM
  • External source of data
  • Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
