• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1969/1970

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 132283

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors
• BF184 BC108 AC150 BFY39 AC151 AC117 AD131 AA119

• Main principle
• Superhet with RF-stage; ZF/IF 452 or 460 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12; 24 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 20 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Omnibus Anlage München III 7.639.529 - Blaupunkt Ideal, Berlin,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 138 x 183 x 125 mm / 5.4 x 7.2 x 4.9 inch

• Notes

• Halbleiter teilweise mehrfach vorhanden.
  Omnibus-Übertragungsanlage München III bestehend aus Empfängerteil Stuttgart ohne NF-Stufe, mit Bedienungsteil und Leistungsverstärker;
  Anschlüsse für 8 Innen-, 1 Kontroll- und 1 Außenlautsprecher.

• Source of data
• Handbuch VDRG 1969/1970

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Richard Winter. See "Data change" for further contributors.
