Stereo Console 12932 GB Version
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1961/1962 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 139775
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110 - 240 Volt
- Loudspeaker
- 4 Loudspeakers
- from Radiomuseum.org
- Model: Stereo Console 12932 [GB Version] - Blaupunkt Ideal, Berlin,
- Notes
- Wavebands: SW 5,9 - 18,2 Mc, MW 515 -1620 Kc, LW 148 - 400 Kc, VHF 87,6 - 104 Mc
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Helmut Arzt. See "Data change" for further contributors.
