Matrix 805

Bowers & Wilkins (B&W); Worthing

Data
Forum
Pictures
Collections

  • Year
  • 1991
  • Category
  • Loudspeaker, headphone or earphone
  • Radiomuseum.org ID
  • 315631

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Matrix 805 - Bowers & Wilkins B&W; Worthing
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 260 x 407 x 210 mm / 10.2 x 16 x 8.3 inch
  • Notes

  • 2 way hi-fi stand-mount/bookshelf loudspeakers housed in wooden cabinets finished in Black Ash, Walnut or Rosewood with a black cloth grille.

    Description 2 way vented box system
    Drive Units 1 x 25mm metal dome - high frequency
    1 x 165mm Kevlar bass/midrange
    Frequency Response 52Hz - 20kHz x 3dB on reference axis
    Sensitivity 87dB spl(2.83V 1m)
    Nominal Impedance 8 ohms (minimum 4 ohms)
    Power Handling 50W - 120W into 8 ohms on unclipped programme



  • Mentioned in
  • - - Manufacturers Literature (Matrix 805 Stand-mount/Bookshelf loudspeaker system brochure)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
