Stereo Mini System MD-K2222

CCE - Indústria e Comércio de Componentes Eletrônicos (Kenwood); São Paulo

Data
Forum
Pictures
Collections

  • Year
  • 2005 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 280878

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Other Combination - see Notes; Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 18 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Stereo Mini System MD-K2222 - CCE - Indústria e Comércio de
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 235 x 322 x 244 mm / 9.3 x 12.7 x 9.6 inch
  • Notes

  • FM MW PLL radio with CD player and cassette deck rec-play

    MW = 520 to 1650 kHz
    FM = 87.5 to 108.1 MHz

    2 channel stereo, remote control
    Clock and timer functions

    Output power = 2 x 9W rms @ 1 kHz, 10% THD
    Supplied with two speaker box, bass reflex type, 4.5 inch speaker
    Speaker box dimensions = 197 x 310 x 184 mm, 2 kg each, 8 Ohms

  • Net weight (2.2 lb = 1 kg)
  • 3.1 kg / 6 lb 13.3 oz (6.828 lb)
  • Literature/Schematics (1)
  • Manufacturer literature
  • Author
  • Model page created by Antonio Rabitti. See "Data change" for further contributors.
