671D Ch= 120137-D
Emerson Radio & Phonograph Corp.; New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- Emerson Radio & Phonograph Corp.; New York, NY
- Year
- 1951 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 38668
-
- alternative name: Emerson Television
Beitman
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: 671D Ch= 120137-D - Emerson Radio & Phonograph
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Notes
- BC (540-1620kHz) band. Built-in loop antenna.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 11, 1951
- Literature/Schematics (1)
- Rider's Perpetual, Volume 22 = covering 1951
