• Country
• United States of America (USA)

• Manufacturer / Brand
• Sentinel Radio Corp., Evanston, Illinois

• Year
• 1939/1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 227330

• Number of Tubes
• 5

• Valves / Tubes

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 195ULTO or 195ULTW - Sentinel Radio Corp., Evanston

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 10.5 x 7 x 7.25 inch / 267 x 178 x 184 mm

• Notes

• Tunes 540 to 1720 k.c. The Sentinel model 195ULTO is in Onyx, the model 195ULTW in Walnut.

• Literature/Schematics (1)
• Table Top Radios Vol. 1 Stein 98 (page 140.)

• Literature/Schematics (2)
• Machine Age to Jet Age II

• Literature/Schematics (3)
• Shown for Season 1939/40 for 1940 in Sentinel Folder No. 120.

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.
