Cruz del Sur TV (FE) 127 /23 1968 con PCC85
Telefunken Radiotécnica Ibérica; Getafe
- Country
- Spain
- Manufacturer / Brand
- Telefunken Radiotécnica Ibérica; Getafe
- Year
- 1968
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 301396
todocoleccion capacabanna 70282981
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Valves / Tubes
- EF183 EF183 EF184 PCL200 ECH84 EF80 PCL86 ECH84 PCL85 PCC85 PL500 PY88 DY87 A59-12W/2
- Number of Transistors
- 4
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Cruz del Sur TV 127 /23 [1968 con PCC85] - Telefunken Radiotécnica
- Shape
- Tablemodel, low profile (big size).
- Notes
-
TV B/N con sintonizador transistorizado de VHF/UHF y TRC de 23"
Dos altavoces elípticos, uno de 6" x 10" y otro de 3" x 5" y uno de 4"Ø
Variante con respecto al FE127/23 del año anterior cambiando la PC92 por una PCC85 para incorporar sincronismo automático de imagen.
