101NU71
|
Country:
Czechoslovakia
|
|
| Identical to |
101NU71
|
| Base |
Wires
|
| Description |
Material/Aufbau/Pol.: Germanium _______ NPN;
Form/Case: ~ TO-1 / TO-18-L;
Daten/electr.data: I F: 10 mA; U F: 6 V; Isp: 10 µA; ß (beta): 45-120; N: 125 mW; Imax(Ic): 250 mA; Umax(Uce): 30 V; f g(FT): 0.7 MHz; tmax: 75 °C.
-
|
Dimensions (WHD)
incl. pins / tip |
6 x 10 x mm / 0.24 x 0.39 x inch |
| Weight |
1 g / 0.04 oz |
| Information source |
- - -
- - - Tesla Katalog
- - -
- - -
|
101NU71: electronica 112
Egon Strampe
|
|
|
|
|
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):7
