12AV5GA

Information - Help
ID = 5287



Tube type:  Beam Power Tube   Power/Output
Identical to 12AV5GA
Similar Tubes
Heater different:
  25AV5GA ; 6AV5GA

Base Octal (Int.Octal, IO) K8A, USA 1935
Was used by Radio/TV-reception etc.
Filament Vf 12.6 Volts / If 0.6 Ampere / Indirect / Specified current AC/DC ~ = (Series working)
Tube prices 2 Tube prices (visible for members only)
Information source Essential Characteristics, GE 1973

12AV5GA: Internet
Miguel Angel Trujillo-Rodriguez

oc73.png 12AV5GA: RTT 1974 (Franzis) 13. Auflage
Martin Renz


Just Qvigstad
12AV5GA: RCA Tube Manual
Peter Hoddow

More ...
Usage in Models 31= 1956? ; 336= 1958?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):367
