2N1309

Information - Help
ID = 36179

Country:
United States of America (USA)
Brand: Common type USA tube/semicond.
Developer: Texas Instruments, Dallas
Tube type:  Transistor   Universal
Identical to 2N1309
Similar Tubes
Normally replaceable-slightly different:
  2N1305 ; 2N317 ; 65T1 ; ASY27
First Source (s)
Mar.1959 : -- Collector info (Sammler)
Base Wires
Description PNP germanium alloy transistor intended as high-speed switch.
-
Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip		 9 x 7 x 8 mm / 0.35 x 0.28 x 0.31 inch
Weight 1 g / 0.04 oz
Information source -- Collector info (Sammler)   KTT 1969/70, TTT Steidle 1981
2N1309: Personal file
Antonio Rabitti
to5_tvt_160.gif 2N1309: TVT 73
Günther Stabe † 19.8.20
2N1309: Valvo Taschenbuch 67
Heinz Höger
More ...
Usage in Models 1= 1962? ; 1= 1963?? ; 1= 1964?? ; 2= 1965?? ; 1= 1965 ; 1= 1968 ; 1= 1970?? ; 1= 1972?? ; 1= 1972?
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):10
