AD1/350

Information - Help
ID = 15538

Country:
Germany
Brand: Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Tube type:  Triode, vacuum   Power/Output
Identical to AD1/350 = 4683
Similar Tubes
Different maximum ratings:
  AD1
Other base and data slightly different:
  P15/250
First year 1938 Tube leaflet collection E.Erb Analysis by original leaflets = 1939

Base Europe side contact P8A (Au P, 8SC) (Codex=So)
Was used by Radio/TV-reception etc.
Filament Vf 4 Volts / If 0.9 Ampere / Direct / Specified voltage AC/DC
Tube prices 6 Tube prices (visible for members only)
Information source Taschenbuch zum Röhren-Codex 1948/49

AD1/350: Röhrenkartei Drenkelfort
Peter Hoddow

21_1.png AD1/350: Telefunken Werkstattbuch
Wolfgang Bauer


Just Qvigstad
AD1/350: Ratheiser RTH,3.Aufl.,1964
Egon Penker

More ...

Collection of

Collection of a member from D
