E355D
|
Country:
Germany
|
|
| Identical to |
E355D
|
| Base |
SPECIAL TUBEBASE in general
|
| Description |
Aufbau/internal: IC (Logik-TTL Digital) Timer, I²L-Technik;
Form/Case/Outline: DIP-18;
Daten/electr.data: Vcc: bei 5V (TTL-kompatibel) Icc: 7mA; fop: <105kHz (max); top: -25°C... +85 °C;
-
|
Dimensions (WHD)
incl. pins / tip |
22 x 7 x 8 mm / 0.87 x 0.28 x 0.31 inch |
| Weight |
2 g / 0.07 oz |
E355D: rfe 5/80
Egon Strampe
|
|
|
|
E355D: Peter Pfeiffer
Peter Pfeiffer
|
