КТ815kt815

Information - Help
ID = 40064

Country:
Soviet Union
Brand: Common type USSR (SU) tube/semicond.
Tube type:  Transistor   Power/Output
Identical to КТ815
Similar Tubes
Normally replaceable-slightly different:
  2Т9139 ; BD135 ; BD137 ; BD139
Base Wires
Description

NPN silicon transistor intended as AF power amplifier.
-


Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip		 8 x 12 x 3 mm / 0.31 x 0.47 x 0.12 inch
Weight 3 g / 0.11 oz
КТ815: tele-Star
Egon Strampe     More ...
kt814817_2.png КТ815: radio fernsehen elektronik 11/81
Egon Strampe
More ...
КТ815: radio fernsehen elektronik 11/81
Egon Strampe
Usage in Models 1= 1977 ; 1= 1979 ; 1= 1980 ; 1= 1981? ; 2= 1984 ; 2= 1985 ; 2= 1986 ; 1= 1988 ; 2= 1989 ; 1= 1990??
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):14

Collection of

Peter Pfeiffer (D)
Egon Strampe (D)
Michael Mischke (D)
