L78Sxx

Information - Help
ID = 50800

Country:
Italy
Brand: Common type Italy tube/semicond.
Tube type:  IC - Integrated Circuit   Power-supply
Identical to L78Sxx
Similar Tubes
Normally replaceable-slightly different:
  LM340K-xx ; µA78Sxx ; µA78xxK
Different maximum ratings:
  L78S12

Base SPECIAL TUBEBASE in general
Description All members of the L78Sxx family (2 A) on one sheet...
Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
27 x 39 x 10 mm / 1.06 x 1.54 x 0.39 inch
Weight 14 g / 0.49 oz
Information source -- Original-techn. papers.   ST SGS Thomson

L78Sxx: STM
Günther Stabe † 19.8.20
    More ...
l78sxx_s_to3.png L78Sxx: STM
Günther Stabe † 19.8.20

More ...
L78Sxx: STM
Günther Stabe † 19.8.20

More ...
Usage in Models 1= 2001?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):1

Collection of



L78Sxx
