MJ1000

Information - Help
ID = 39608

Country:
United States of America (USA)
Brand: Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
Tube type:  Transistor   Power/Output
Identical to MJ1000
Similar Tubes
Normally replaceable-slightly different:
  2N6055 ; 2SD523
Different maximum ratings:
  BDX65 ; MJ3000
Base SPECIAL TUBEBASE in general
Description NPN silicon diffusion planar darlington transistor intended as AF power amplifier.

Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip		 26 x 39 x 9 mm / 1.02 x 1.54 x 0.35 inch
Weight 12 g / 0.42 oz
Information source - - -
- - -   TTT Steidle 1981
- - -
- - -
MJ1000: T 5626
Egon Strampe
to3_169.gif MJ1000: TTT Steidle 1981
Günther Stabe † 19.8.20
MJ1000: National Semiconductor 1978
Heinz Höger
More ...
Usage in Models 1= 1975?? ; 1= 1979?
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):2

Collection of

Museum Roggenhofer (A)
Karlheinz Fischer (D)
Nikolaus Löwe (D)
