MOC3010
|
Country:
United States of America (USA)
|
|
| Identical to |
MOC3010
|
| Base |
SPECIAL TUBEBASE in general
|
| Description |
Aufbau/internal: IC (GaAs Diode, Logic, Triac);
Form/Case/Outline: DIP-6;
Type/Application: Random-Phase Opto-Isolator, Triac Driver Output, IFT: 15 mA max.;
Daten/electr.data: IR Diode = Vr: 3 V, If: 60 mA, Pd: 100 mW; Output Driver: Vdrm: 250 V, Itsm: 1 A, Pd: 300 mW; t op: -40...+85 °C;
-
|
Dimensions (WHD)
incl. pins / tip |
8 x 7 x 8 mm / 0.31 x 0.28 x 0.31 inch |
| Weight |
1 g / 0.04 oz |
| Information source |
- - Manufacturers Literature Fairchild
|
MOC3010: Motorola
Günther Stabe † 19.8.20
|
MOC3010: Motorola
Günther Stabe † 19.8.20
|
|
|
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):1
