NCP1203

Information - Help
ID = 78608

Country:
United States of America (USA)
Brand: Common type USA tube/semicond.
Tube type:  IC - Integrated Circuit   Power-supply
Identical to NCP1203
Base SPECIAL TUBEBASE in general
Description

Aufbau/Content: IC (CMOS);
Form/Case/Outline: DIP-8 (NCP1203Nxx) | SOIC-8 (NCP1203Dyxx);
Application/Type: PWM Current-Mode Controller for Universal Off-Line Supplies featuring Standby and Short Circuit Protection;
Daten/electr.data: Vcc: 12.8 V; Icc: <2 mA; xx = f: 40 / 60 / 100 kHz; Pd: __ W; tmax j: 150 °C;
Pin compatible with NCP1200;
Manufactured by ON Semiconductor (USA)
-


Dimensions (WHD)
incl. pins / tip		 10 x 7 x 8 mm / 0.39 x 0.28 x 0.31 inch
Weight 1 g / 0.04 oz
Information source - - Manufacturers Literature
NCP1203: ON
Günther Stabe † 19.8.20
ncp1203_s.png NCP1203: ON
Günther Stabe † 19.8.20
NCP1203: ON
Günther Stabe † 19.8.20
