• Country
• Japan

• Manufacturer / Brand
• Aciko (brand)

• Year
• 1988 ??

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 225091

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 5

• Semiconductors
• 2SC380 2SC941 2SC941 2SC380 2SC1959 KIA7343 TDA2005 TDA2005 1N60 1N60

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 13,2 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 25 W (max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: AR 904 - Aciko brand

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 178 x 44 x 145 mm / 7 x 1.7 x 5.7 inch

• Notes

• Dial lamp: 14V/0,06A.

  Output: Stereo 2x 25W.

  Apart from the listed ICs the schematic also contains the ICs  KIA7303, KIA7325 and BA3822.

• Net weight (2.2 lb = 1 kg)
• 1.5 kg / 3 lb 4.9 oz (3.304 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
