• Country
• Japan

• Manufacturer / Brand
• Aciko (brand)

• Year
• 1973 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 236271

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player; Radio with other functions

• Power type and voltage
• Line / Batteries (any type) / 110-117; 220-240 / 6× 1,5 D Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Radio-Phono-Cassette Tape Recorder ACRT 820S - Aciko brand

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 405 x 90 x 295 mm / 15.9 x 3.5 x 11.6 inch

• Notes

• Record player with 33, 45 & 78 rpm, cassette recorder, battery indicator.

  See also Three in One FKPC-717

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
