- Country
- United States of America (USA)
- Manufacturer / Brand
- Federated Purchaser, Inc. (Acratone, Acratest); New York City (NY)
- Year
- 1933
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 31164
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification; 3 AF stage(s)
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- - For headphones or amp.
- from Radiomuseum.org
- Model: Acratest 120 - Federated Purchaser, Inc.
- Notes
- Push pull output stage. Both input and output high and low impedance.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 6 = 1935 and before
