• Country
• United States of America (USA)

• Manufacturer / Brand
• Admiral (brand) Continental Radio & Television Co.; Chicago, IL

• Year
• 1950 ?

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 248445

• • alternative name: Continental Radio & TV

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• 6A5 6J6 6AU6 6AL5 6SN7GT 6AS5 6AU6 6AU6 6AU6 6AL5 6AU6 12AU7 12AU7 6SN7GT 6BG6G 1X2 6W4GT 5U4G 12LP4

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: 32X27 Ch= 20Z1 + 5B2 - Admiral brand Continental

• Notes

• TV - Radio - Phono combination.

  TV-Tuner = 94C21-2
  Radio chassis     = 5B2
  Record changer = RC500

  Power supply = 2PA1.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 91A Folder 1 1950)

• Author
• Model page created by Geert Schulte. See "Data change" for further contributors.
