• Country
• United States of America (USA)

• Manufacturer / Brand
• Admiral (brand) Continental Radio & Television Co.; Chicago, IL

• Year
• 1957 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 83841

• • alternative name: Continental Radio & TV

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• 2N219 or. 2N412 2N218 or. 2N410 2N218 or. 2N410 93A9 2N217 or. 2N408 2N217 or. 2N408 2N217 or. 2N408 1N295

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries / 4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.75 inch = 7 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 7M14 Ch= 7M1 - Admiral brand Continental

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 5.875 x 3.375 x 1.75 inch / 149 x 86 x 44 mm

• Notes

• Admiral model 7M14 is a battery operated portable AM transistorized receiver.

  The following models are identical except for cabinet color.

  Model	Cabinet Color
  7M11	Ebony
  7M12	White & Red
  7M14	White & Tan
  7M15	unknown
  7M16	White & Yellow
  7M18	White & Turquoise

• Price in first year of sale
• 40.00 $

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 18, 1958

• Mentioned in
• Collector's Guide To TrR1 Bunis trans.94 (1996, page 9)

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 369 Folder 1 dated 9-57)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
