- Country
- United States of America (USA)
- Manufacturer / Brand
- Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 31360
-
- alternative name: Continental Radio & TV
Sams Photofact
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 10700/455 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 7 C 73 Ch= 9A1 - Admiral brand Continental
- Shape
- Console with any shape - in general
- Notes
-
Automatic Record Changer Admiral Model RC170A.
Left fold down phono door. Cabinet of choicest veneers: walnut, mahogany or bleached.
- Price in first year of sale
- 289.95 $
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 17 = 1948 and before
- Mentioned in
- Guide to Old Radios
- Literature/Schematics (1)
- Collector's Guide to Antique Radios (6th edition)
- Literature/Schematics (2)
- Radio Retailing (Radio & Television R.) (June 1947 page 17/18. August 1947 page 47.)
- Literature/Schematics (4)
- Photofact Folder, Howard W. SAMS (Set 32, Date 1/48, Folder 482-1)
