• Country
• USA (Stati Uniti d'America)

• Manufacturer / Brand
• Admiral (brand) Continental Radio & Television Co.; Chicago, IL

• Year
• 1957 ?

• Category
• Televisore (TV) / Monitor

• Radiomuseum.org ID
• 311474

• • alternative name: Continental Radio & TV

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 4BZ7 5J6 3CB6 3CB6 5AM8 5AN8 3AU6 3AL5 12AC5 6CG7 6S4A 6CG7 12DQ6 12AX4GTA 1B3GT 21ATP4B

• Main principle
• Supereterodina con stadio RF

• Wave bands
• Gamme d'onda nelle note.

• Power type and voltage
• Alimentazione a corrente alternata (CA) / 60 Hz, 117V = 110 -120 Volt

• Altoparlante
• AP magnetodinamico (magnete permanente e bobina mobile)

• Materiali
• Mobile in legno

• from Radiomuseum.org
• Model: C23A1C Ch= 17Z3DB - Admiral brand Continental

• Forma
• Soprammobile con qualsiasi forma (non saputo).

• Notes

• Admiral model C23A1C is a 21" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 17Z3DB, VHF tuner 94E140-1 and picture tube 21ATP4B.

• Letteratura / Schemi (1)
• Photofact Folder, Howard W. SAMS (Set 363 Folder 2 Dated 57-7)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
