Clipper Three Band Y2137 Ch= 8C2

Admiral (brand) Continental Radio & Television Co.; Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1960 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 138893
    • alternative name: Continental Radio & TV

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Dry Batteries / 6 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Clipper Three Band Y2137 Ch= 8C2 - Admiral brand Continental
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes

  • Admiral Clipper Three Band, Y2137 Ch= 8C2;
    SW: 2.0 - 16 MHz, normal-navig. switch, socketed 2N type transistors, semi-cycle scale.

    8x transistors, 2x diodes, 3x antennas.

  • Price in first year of sale
  • 99.95 USD
  • Source of data
  • -- Collector info (Sammler)
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
