T103 Ch= 14YP3B
Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Year
- 1956 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 260476
-
- alternative name: Continental Radio & TV
Picture from service manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: T103 Ch= 14YP3B - Admiral brand Continental
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The Admiral T103 is a 10" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 14YP3B and picture tube 10ABP4.
