- Country
- United States of America (USA)
- Manufacturer / Brand
- Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Year
- 1963/1964
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 92208
-
- alternative name: Continental Radio & TV
RECONSTRUCTED LABEL
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Y3503 Ch= 4A4 - Admiral brand Continental
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
- Beitman 1965 and SAMS Photofact (Date 7-64, set 705, folder 5) list the Admiral models Y3503, Y3508 and Y3509 (color gray) for chassis 4A4. All are AC-DC 4 tube AM receivers with only 4 tuned circuits (for local stations) with a loop antenna. They differ only in color and have two knobs. We believe that Y3503 is in some sort of white and Y3508 in some sort of green. For more information on the Y-models see this link.
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 25, 1965
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 7-64, set 705, folder 5, title copy)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
