• Country
• United States of America (USA)

• Manufacturer / Brand
• Admiral (brand) Continental Radio & Television Co.; Chicago, IL

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 243064

• • alternative name: Continental Radio & TV

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AV6 50C5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 60 cycle, 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: YG777 Ch= 5D6E - Admiral brand Continental

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Notes

• The Admiral YG777 is an AC operated 5 tube BC band clock radio.  BC band frequency range is 535 to 1620kHz. Cabinet color is beige.

  The following models use the same schematic and cabinet but have different cabinet colors:

  Model Number	Cabinet Color
  YG773	White
  YG774	Pink
  YG777	Beige



• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• - - Manufacturers Literature (Admiral Datasheet Supplement S977B Dated 6/65)

• Literature/Schematics (2)
• - - Manufacturers Literature (Admiral Datasheet S977 Dated 11/63)

• Literature/Schematics (3)
• Photofact Folder, Howard W. SAMS (Set 712, Folder 5, October 1964)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
