Iren' - Ирень RP-301 - РП-301

• Country
• Soviet Union

• Manufacturer / Brand
• ADS Plant, Perm, Russia

• Year
• 1990/1991

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 136447

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Iren' - Ирень RP-301 - РП-301 - ADS Plant, Perm, Russia

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 63 x 105 x 25 mm / 2.5 x 4.1 x 1 inch

• Notes
• 2 IC-s, 1 Mosfet, Varicap tunning, FM OIRT 64,8-74 MHz. The first only FM portable radio set in Soviet Union.

• Net weight (2.2 lb = 1 kg)
• 0.1 kg / 0 lb 3.5 oz (0.22 lb)

• Price in first year of sale
• 30.00 RUB

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 3 models, 2 with images and 3 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
