HF Analyst SWR-121

• Country
• United States of America (USA)

• Manufacturer / Brand
• Advanced Electronic Applications, Inc. (AEA); Lynnwood, WA & Vista, CA

• Year
• 1993 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 343390

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Power type and voltage
• Dry Batteries

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: HF Analyst SWR-121 - Advanced Electronic

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Author
• Model page created by David Erali. See "Data change" for further contributors.

• Other Models

• Here you find 14 models, 12 with images and 9 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
