- Country
- Germany
- Manufacturer / Brand
- AEG (Radios) Allg.Elektricitäts-Ges.
- Year
- 1944
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 212
ebay 141591491169, w3l
orlando8221 170569810549
orlando8221 170569810549
ebay 141591491169, w3l
ebay 141591491169, w3l
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 473 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- AC/DC-set / 110-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 4313GW - AEG Radios Allg.Elektricitäts-
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 560 x 320 x 260 mm / 22 x 12.6 x 10.2 inch
- Notes
-
Schaltplan datiert vom April 1944.
- External source of data
- Ernst Erb, HB9RXQ
