• Country
• Germany

• Manufacturer / Brand
• AEG (Radios) Allg.Elektricitäts-Ges.

• Year
• 1952/1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 258

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• ECH42 EF85 EBF15 EF11 EM71 EM11 EL11 EAA91 EF804 EF804 EDD11

• Main principle
• Superheterodyne (common); ZF/IF 452/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player + Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 25 cm = 9.8 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Univox Junior 51WU - AEG Radios Allg.Elektricitäts-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 680 x 450 x 440 mm / 26.8 x 17.7 x 17.3 inch

• Notes
• Rundfunkchassis 51WU: Variable Bandbreite, KW-Lupe.
  Zweispur-Tonbandgerät KL 15, Bandgeschwindigkeit 19 cm/s; 3 Tonköpfe; Frequenzumfang 50···10000 Hz.
  Plattenspieleinrichtung: Plattenschonender Kristall-Tonarm mit Saphir-Dauernadel.
  Preis komplett mit Mikrofon, Leerspule und Plattenspieleinrichtung.

• Net weight (2.2 lb = 1 kg)
• 28 kg / 61 lb 10.8 oz (61.674 lb)

• Price in first year of sale
• 1,430.00 DM

• Source of data
• Lange, Schaltungen der Funkindustrie / Radiokatalog Band 1, Ernst Erb

• Mentioned in
• Kat.d.Rundf.GrossH.1952/53
