- Country
- Germany
- Manufacturer / Brand
- Aeriola Ges.m.b.H.; Berlin
- Year
- 1925/1926
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 13842
-
- Brand: Radio-Baby
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- TRF with regeneration; 1 AF stage(s)
- Tuned circuits
- 1 AM circuit(s)
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case, TUBES VISIBLE.
- from Radiomuseum.org
- Model: E10 - Aeriola Ges.m.b.H.; Berlin
- Dimensions (WHD)
- 210 x 100 x 130 mm / 8.3 x 3.9 x 5.1 inch
- Notes
- Spulenkoppler; Spulen in Bakelitgehäuse
- Net weight (2.2 lb = 1 kg)
- 1.2 kg / 2 lb 10.3 oz (2.643 lb)
- Price in first year of sale
- 70.00 RM
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Mentioned in
- Radios von gestern, 1. Auflage
- Picture reference
- Das Modell ist im «Radiokatalog» (Erb) abgebildet, das Copyright liegt beim Deutschen Rundfunk Museum (DRM), Berlin und beim Archiv-Verlag (AV). Sie finden eine grössere Abbildung und Schaltbild etc. bei der Loseblatt-Sammlung von DRM/AV.
