• Country
• United States of America (USA)

• Manufacturer / Brand
• Affiliated Retailers, Inc.; New York (NY)

• Year
• 1950 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 31493

• • Brand: Artone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6BA6 12AT7 6BA6 6BA6 6T8 6BE6 7A5 5Y3GT

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 105 - 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• Power out
• 3.2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: AR-252MU - Affiliated Retailers, Inc.;

• Shape
• Console, Lowboy (legs < 50 %).

• Notes
• Color=Mahogany

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 21, Copyright 1950

• Other Models

• Here you find 59 models, 24 with images and 55 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Affiliated Retailers, Inc.; New York (NY)
